New Folding end mirrors available from Joker Machine in 3 styles!. These mirror are inspired by aircraft structural design combined with the unique "road racer" or "cafe racer" styling. Our mirror heads and mounting parts are completely CNC machined from billet aluminum, super light-weight, strong, and fully adjustable in a multitude of directions and settings. (ALL PARTS ARE ANODIZED FOR DURABILITY) .Mirror heads swivel (fold) a full180 degrees frontwards & backwards,… a full360 degrees rotational on the bracket arm, plus the bracket arm may be rotated up or down to your desired position on the bar mounting shaft. All rotational tension of the parts may be set to your preference with an allen wrench, and all hardware is top quality heat treated alloy with plated with our "GOLD CAD" finish for strength and durability.
All moving parts feature super smooth pivoting action due to the use of nylon spacers between the mating parts. These mirrors provide EXCEPTIONAL rear visibility due to the use of OUR EXCLUSIVEcustom-made CONVEX mirror glass.
(RECTANGLE)= 1 1/2"(38MM) X 3 1/2"(88.83MM).FOLDING MIRROR HANDLEBAR MOUNT OPTIONS BELOW:
FOR TRIUMPH STOCK 1" BARS WITH THREADED LUG INSIDE OF THE BARS:
USE THE SPECIAL MOUNT SECTION SHOWN ABOVE (IN YELLOW WRITING). IT REPLACES THE SILVER WASHERS ON THE ENDS OF THE STOCK GRIPS. JUST UNSCREW THE PRE-EXISTING UNITS, THEN MOUNT OURS, THEN MOUNT THE MIRROR – SIMPLE!
BAR EXPANDER TYPE MOUNT INSIDE DIA. EXPANDING RANGE SPECS:
